The SieStar C10 BESS is a compact, modular 10-foot container with an energy capacity up to 645 kWh. This solution offers scalable energy storage, with expandable clusters of 215 kWh each and a bi-directional inverter up to 312.5 kW. The integrated EMS, based on Siemens technology, supports on- and off-grid applications such as peak shaving and load capacity buffering. The container is designed to be safe and efficient with fire-resistant, climate-controlled compartments and reliable LiFePO4 battery modules. Ideal for diverse power management needs.

C10
  1. Home -
  2. Products -
  3. C10

Modular

The SieStar battery energy systems are prepared for expansion within the existing housing. The system can expand from one to multiple units, allowing storage capacity to grow with your business needs and rising energy requirements.

Integrated EMS

Integrated EMS
The SieStar Energy Management System (EMS) manages energy flows behind the meter and regulates consumption and feed-in to the grid in accordance with the contracted capacity. It offers functions such as peak shaving, load shifting, emergency power supply, smart charging, (thermal) energy buffering and energy trading.

Safety

The systems are built in accordance with PGS37.1 and offer 60 minutes of fire resistance. Equipped with a two-stage fire alarm system with PAC transmission and remote emergency stop, they are inaccessible and switch off automatically when the service door is opened.

LiFePO4 batteries

SieStar offers up to 10 years or 6,000 cycles warranty. The LFP battery cells are assembled in Terneuzen and offer optimal stability and energy transfer. Benefits include a long service life, fire safety and active balancing for 15% longer service life.

Modular
Integrated EMS
Safety
LiFePO4 batteries

Specifications

Discover the C10 and its specifications.

BESS
Cluster
Battery Module
Battery cell
Dimensions (L*W*H) 2991 * 2438 * 2591 mm
Weight (ca.) 7,000 to 10,000 kg
Smart EMS Safety-PLC monitoring via 10’’ HMI and app
Communication protocols Modbus TCP, API’s, Profibus, Profinet and more
PCS – bi – directional 600-900 V DC – 400 V AC
Flexible configuration 62.5 to 312,5 kW by means of 1 to 8 modules
Battery to system protection to 3-level BMS
in accordance with PGS37.1
BESS
12 battery modules with 1 DC control box per cluster
215 to 645 kWh by means of 1 to 3 clusters
Nominale voltage 768 V DC
Smart active balancing (high electric current) Results in ca. 15% longer lifespan and shorter charging times
Cluster
Weight 134 kg
Dimensions (L*B*H) 900*440*240 mm (max. 952*483*240 mm)
Nominale voltage 768 V DC
Type of cooling Forced ventilation – PWM monitored
17.92 kWh
Certification IEC62619, UN38.3
Battery Module
Nominal capacity 280 Ah
LiFePO4 (LFP) prismatic
Nominal voltage 3.2 V DC
Battery cell

Download the factsheet

Want to know more about our product? Download our factsheet for extensive information and discover the advantages of our solutions.

Download the leaflet

Request a quote

Interested in our products? Request a quote and receive 100% advice without obligation on the solutions to your energy problems.

Suitable for your situation

There is a suitable solution for every company, problem and situation. At SieStar, we believe in tailor-made solutions specific to your problem. Together, we take control of your energy.
